DM 9600 CHP Precision Manometer for numerous pressure-, differential pressure- and temperature-measurements at CHP engines
- Data transfer via Bluetooth to App
- Long-term stable pressure sensor with a range of up to 10 bars (145 psi)
- Twin K-type thermocouple sockets for temperature measurements
- Optional gas leackage detector
- Modern, rugged unit with bluetooth, colour touch screen, USB, SD-Card, etc.
Basic-Equipment
- Electronic, long-term stable pressure sensor for up to 10 bars (100 psi)
- Twin K-type (NiCrNi) thermocouple temperature sockets
- Indication in hPa / mbar / bar / psi / mmHg / inchHG / cmH2O / inchH2O
- Temperature indication optionally as °C or °F
- Bluetooth for wireless data transfer to MRU4u app (Android & IoS)
- AUX connector for external pressure transmitter or gas sniffer
- USB interface for cable data transfer and battery charger
- Internal data storage for thousands of measurements!
- High volume data storage to SD card (CSV format)
- Min/Max recording, programable average value
- Automatic and continuously monitoring of pressure/negative pressure
- Stainless steel fast coupling connectors
- Brilliant 2,8" TFT touchdisplay
- Glass-fiber reinforced housing with integrated magnets
- High energy Li-Ion battery, Auto-Off-Function
- Wall plug battery charger (EU only) with USB cable
Options
App MRU4u
for remote control and visualization of measuring data
PC software MRU4win
for PC visualization of measured data
Accessories
Quick coupling set (2pcs)
self-locking quick coupler for intake of 6/8 mm hose
Stauff pressure hose
2 m length, with Stauff 20/20 (M16x2 mm) test fitting to manometer quick coupling
Robust transport case DELTAsmart
with compartments for accessories
Universal temperature probe
various lengths up to 1.000 mm, Ø 4,5 ... 6 mm, up to 1.000° C
Thermocouple K clamp contact probe
-50 ... +250° C, pipe Ø up to 60 mm, 2 m cable
Detector probe
- Detector probe for fast leakage detection
- 1,95 m cable and flex. goose neck
- adaptable to all AUX sockets
Sensor for HC leakage detection
adaptable to detector probe (plug and play)
Calibration adaptor kit for gas sniffer
incl. pressure regulator and sensor manifold
Speed printer
Infrared high speed thermal printer
Printer paper
for speedprinter
Technical Data
Measuring range
| Measuring range | internal sensor: 0…10 bar (145 psi) |
Dimensions and other data
| Weight | approx. 400 g |
| Measuring units | mbar/ bar/ hPa/ psi/ mmHg/ inchHG/ cmH2O/ inchH2O |
| Zero point | Automatic |
| Display | 2.8" colour TFT, touchscreen |
| Interfaces | Mini-USB, Micro-SD, Bluetooth, IR for printer and AUX socket for ext. pressure transmitter and leackage detector |
| Battery capacity | approx. 20 hours with Lithium-Ion battery |
| Dimensions | (W x H x D) 82 x 169 x 36 mm |
| Data storage | internally 10.000 data sets or ext. Mirco-SD card |
| Data transfer | to MRU4win PC-software or MRU4u App |
| Power supply | wall plug USB-charger 100…240 Vac, 50…60 Hz |
Downloads
User manual DM9600 CHP
PDF, 2 MB
EN_FLYER_DM9600-CHP.pdf
PDF, 2 MB
